Configurations
|
Monitor |
7.0 inch color monitor |
Speed |
200-1200RPM |
|
Therad Borken detect |
Top thread+ substrate thread detect |
Main motor |
Servo motor 0.4 Kw |
|
Input |
USD3.0 |
Assistance motor |
XY stepping motor |
|
Memory |
20,000,000 stitches/1000 designs |
Stitch length |
0.1-12.7mm |
|
Shaft configure |
Janpanese KOBAN hook/needle |
Power |
0.3Kw |
|
Drive system |
Double column linear guide/Italy belt |
Electricity supply |
110-270V 50-60HZ |
|
Auxiliary function |
Hoop spacing/Power-off protection/Fault alarm/Emergency cutoff |
||
|
Accessories |
Tools/ Spare parts/Instructions/Factory certificate |
||
Additional Device configurations
|
|
Sequins single/double L/LL |
Simple chain embroidery S |
Simple towel embroidery M |
|
|
Material size |
Ø3-9mm |
Ø0.1-4mm |
800rpm |
|
|
Speed |
700-1000rpm |
800rpm |
600rpm |
|
|
Assemble positon |
Left(last needle)/Right(First needle) |
Under head |
||
|
Assemble direction |
Front / Side —— |
Front |
||
|
Lifting |
Pneumatic/Electrical |
Pneumatic |
||
|
Combination |
L+L LL+LL L/LL+S L/LL+S+M |
|||
1. 7.0 inches LED touch screen.Easy for understand adn opeartion.
Languages including: English, Spanish, Arabic. Customize languages available.
2. Flat embroidery, Garment embroidery(Tubular embroidery),Cap embroidery (Cylinder embroidery)etc. Multi-function transfer easily.
Garment embroidery (Tubular embroidery) with different tabouret sizes available. Maximum 500*360 mm.
3. Cap embroidery (Cylinder embroidery) allows 360 degrees operation.Frame is made of carbon fibre material which is moew convenient.
High intelligence with functions of thread broken detect. Automatic trimming, Fault alarm, intelligent embroidery mending, Power-off protection.
4. Embroidery pattern read via USB connection. Support files in formats DST, ZSK, EXP etc.
Large emory enablles a storage of 20,000,000 stitches/1000 designs(extensible). Independent chip assures that signals transfer stably.
5. System with pattern edit menu.Easy to rotate, zoom etc.
3 ways to change the colors. Automatic, semi-automatic, manual operation.Colors of one pattern can be changes maximum 1000 times.
6. Support single or mixed embroidery of sequin embroidery, sinple towle towel embroidery and chain embroidery.
Trimming and hooking with stepping motor. Trimming stable and length adjustable. Low dropping rate. No Birdnesting.
7. Use AC servo motor for main motor which is able to handle various thickness of embroidery.
Equipped with remote fault analysis and automatic alarm system.
8. Use high speed linear guide to drive the hoops which guarantees the precision of products.
Adopt high-precicion stepping motors. The accuracy reaches 0.1mm/P.
Q1: Are you Manufactory or Trade Company?
A: We are the Manufactory in China.
Q2: What products can you offer?
A: We can offer you bobbin winding machine and accessories, quilting machine, embroidery quilting machine etc.
Q3: How do you control the quality?
We have professional inspectors totest the finished products strictly according to standard stipulated.
You can be assured that all the products you get from us are reliable.
Q4: Can you accept customization?
Yes. If you have special requirements on products or packages, we can do customization for you.
Q5: Can you accept trail orders?
Gemerally our MOQ is 1 ton. But if you want to place a trail order as the beginning of our cooperation,
we can accept smaller quantity at frist. Surely we will have further and longer partnership after the beginning.
